The Spread of Pellets After Shotgun Discharge

As the muzzle of the shotgun is moved farther from the body, tattooing disappears and the diameter of the circular wound of entrance increases in size until a point is reached where individual pellets begin to separate from the main mass.

Click image for larger version

Name:	001.jpg
Views:	368
Size:	295.3 KB
ID:	1036436
Fig.1 The spread of pellets after shotgun discharge.

Click image for larger version

Name:	002.jpg
Views:	386
Size:	534.9 KB
ID:	1036435
Fig.2 Single-round entrance wound. From contact to 2 ft (60cm).

Click image for larger version

Name:	003.jpg
Views:	402
Size:	459.2 KB
ID:	1036437
Fig.3 Entrance wound with scalloped margins. From 3 ft (91cm).

From contact to 2 ft (60cm), birdshot fired from a shotgun, generally, produces a single-round entrance wound (Fig.2). By 3 ft (91cm), the wound widens and the edges of the wounds will have scalloped margins (Fig.3). By 4 ft (121cm), scattered satellite pellet holes are present around the main entrance (Fig.4). By 6–7 ft (182-213cm), there is a definite cuff of satellite pellet holes around a slightly irregular wound of entrance (Figs.5-6). Beyond 10 ft (305cm), there is a great variation in the size of the pellet pattern depending on the ammunition used, the choke of the gun and, most important, the range (Figs.7-8).

Click image for larger version

Name:	004.jpg
Views:	384
Size:	531.0 KB
ID:	1036438
Fig.4 Scattered satellite pellet holes around the main entrance. From 4 ft (121cm).

Click image for larger version

Name:	_005.jpg
Views:	362
Size:	626.3 KB
ID:	1036434
Fig.5 Cuff of satellite pellet holes around irregular wound of entrance. From 6-7 ft (182-213cm).

Click image for larger version

Name:	006.jpg
Views:	408
Size:	406.7 KB
ID:	1036439
Fig.6 Cuff of satellite pellet holes around irregular wound of entrance. From 6-7 ft (182-213cm).

At close range, the shotgun is the most formidable and destructive of all small arms. The severity of the injuries in contact wounds is due to two factors: the charge of shot and the gas from combustion of the propellant (also termed “blast effect”). Most contact shotgun wounds are suicidal in origin. Intermediate-range and close-range shotgun wounds are almost as mutilating as contact wounds because the pellets are still traveling in a single mass.

Click image for larger version

Name:	007.jpg
Views:	390
Size:	268.9 KB
ID:	1036440
Fig.7 Large spread of individual pellet defects. From +10 ft (305cm).

Click image for larger version

Name:	008.jpg
Views:	404
Size:	500.3 KB
ID:	1036441
Fig.8 Spread of buckshot pellets. From +10 ft (305cm).

At the same range, the pattern of different guns and brands of ammunition may vary from a central irregular perforation with numerous satellite wounds to a pattern of multiple individual pellet wounds. In all deaths from shotgun wounds, the size of the shot pattern on the body should be measured so that the range can be determined accurately. The range determinations by size and appearance of pattern given should be used only as a rough guide in estimating range. The only reliable method of determining range is to obtain the actual weapon and the same brand of ammunition used and then conduct a series of test shots so as to reproduce on paper the pattern of the fatal wound on the body.

-

This post is for educational purposes only and is nonprofit. Under Section 107 of the US Copyright Act of 1976; Allowance is made for "Fair Use" for purposes such as criticism, comment, news reporting, teaching, scholarship, and research. OP is not a medical expert. No copyright infringement intended. This post does not encourage or glorify violence/harassment. Images might have been upscaled and enhanced. Text might have been shortened and simplified/reorganized for online view.
